170T - Industrial Display 17" Screen
 Feature
Resistive Touch
17" TFT LCD Monitor TouchScreen with VGA input
One VGA input.
On-Screen-Display
Wire Resistive Touch-Screen
| 170T SPECIFICATIONS |
| Model |
170T - 17" TFT LCD Color display |
| LCD Display |
17" Diagonal |
| Pixel Pitch |
0.297 mm x 0.297 mm |
| Max. Resolution |
XGA 1280 x 1024 |
| Contrast Ratio |
300 : 1 (Typical) |
| Brightness |
300 cd/m2 (Typical) |
| Display Colors |
16.77M(dithering) |
| Viewing Angle |
+65° ~ -65°(L/R), +60° ~ -60°(U/D) (Typical) |
| Video Signal |
0.7V Peak-to-Peak Analog R.G.B. |
| Life of lamp tubes |
40,000 hours |
| Sync |
TTL Positive or Negative |
| Input Connector |
15 Pin D-sub Analog R.G.B. |
| User Controls |
On/Off, Menu Controls: Auto-Adjustment, Contrast, Brightness, Phase, Color Temperature |
| Housing (enclosure) |
Made from 1.6mm thick steel metal sheet.
Ultra ruggedized construction with electro galvanized anti-rust surface treatment. |
| Color of housing |
Silver or Black colors for your selection |
| Wall-mount standard |
Compliant to VESA-75 and VESA-100 universal industrial wall mount standard. Extra 4 hook holes are also provided for easy convenient wall mounting. |
| Power Supply |
Input: 100-240V, 50-60Hz, 1.0A
Output: 12V, 2.9A, 35W Inner Post (+), Outer Ring (-) |
|
 |
|
Order Information
LCM-170T-ALU - 17” with Aluminum front bezel and touch screen
LCM-170-ALU - 17” industrial LCD monitor with Aluminum front bezel
|
|
|
|
|
| © Copyright IBT Technologies Inc., 2010 - All Rights Reserved |
* Information are subject to change without notice, Engineering specs may differ slightly.
* Parts number may differ from ordering information. |
|
